Liquid Transfer Station

The Liquid Transfer Station is designed for loading liquid from storage tanks to mobile application equipment. The Liquid Transfer Station can also be used to unload mobile application equipment back to storage, and for circulating liquid material in storage. Liquid transfer systems are available in single and three phase, 115 Volt and 230 Volt power supplies. Available in 90 and 165 Gallons per minute systems.

Current Stock:

• Bronze or Stainless Steel Pump Head
Corrosion resistance materials needed for transferring abrasive materials like those used in anti-icing applications.

• 316 Stainless Steel Pump Shaft
Heavy duty shaft for added pump life with corrosion proofing for easy maintenance

• Totally Enclosed Fan Cooled (TEFC), Thermally Protected Motors
Available in 115/230 volt

• Mechanical Pump Shaft Seal
Positive sealing design eliminated leakage associated with non-positive seals in higher flow and pressure applications

• Galvanized Frame
Galvanized coating resists scratching and has superior rust protection

• Integrated Hose Storage
Designed to store a variety of hose lengths and sizes

• Pre-Wired, On/Off Control
Ready for use by simply supplying power

• Visual Pump Light
Indicates system on/off for operator safety

• Triple Function
Use system for loading, unloading and circulation of chemical storage

• EPDM Wire Reinforced Hose
Prevents kinks and hose collapse for added system reliability

• Available in 90 and 165 Gallons Per Minute Systems

Call for pricing
